| Manufacturer Part Number: | ZL9101MIRZ |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | DC DC Converters |
| Available Quantity: | 9667 Pieces |
| Unit Price: | Quote by Email |
| Description: | DC/DC CONVERTER 0.54-3.6V 43W |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ZL9101MIRZ Datasheet |
| Internal Part Number | 898-ZL9101MIRZ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Application: Industrial Controls PowerNavigator 5.2 Overview | |
| Featured Product | ZL9101M Digital DC/DC Power Module | |
| PCN Design/Specification | ZL9101M, ZL9117M Firmware Update 13/Sept/2012 Mold Compound Update 26/Nov/2014 | |
| Online Catalog | ZL9101M Series | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Manufacturer | Intersil | |
| Series | ZL9101M | |
| Packaging | Tray | |
| Part Status | Active | |
| Type | Non-Isolated PoL Module, Digital | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 13.2V | |
| Voltage - Output 1 | 0.54 ~ 3.6 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 12A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Applications | ITE (Commercial) | |
| Features | OCP, OTP, OVP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 21-QFN, Variant | |
| Size / Dimension | 0.59" L x 0.59" W x 0.14" H (15.0mm x 15.0mm x 3.5mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 95% | |
| Power (Watts) - Max | - | |
| Standard Package | 96 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ZL9101MIRZ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ZL9101MIRZ is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ZL9101MIRZ is new and unused, you can buy ZL9101MIRZ Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ZL9101MIRZ.
