Manufacturer Part Number: | ZL6105ALAF |
---|---|
Manufacturer: | Intersil |
Product Category: | PMIC - Voltage Regulators - DC DC Switching Controllers |
Available Quantity: | 9813 Pieces |
Unit Price: | Quote by Email |
Description: | Buck Regulator Positive Output Step-Down I²C, PMBus, SMBus DC-DC Controller IC 36-QFN (6x6) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 2 (1 Year) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ZL6105ALAF Datasheet |
Internal Part Number | 898-ZL6105ALAF | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | PowerNavigator 5.2 Overview | |
PCN Design/Specification | ZL6105ALAF Firmware Update 30/Mar/2012 Silicon Design Update 21/Apr/2015 | |
PCN Assembly/Origin | Alternate Facilities 03/Mar/2014 | |
Online Catalog | Buck (Step-Down) IC | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
Manufacturer | Intersil | |
Series | Digital-DC™ | |
Packaging | Tube | |
Part Status | Active | |
Output Type | Transistor Driver | |
Function | Step-Down | |
Output Configuration | Positive | |
Topology | Buck | |
Number of Outputs | 1 | |
Output Phases | 1 | |
Voltage - Supply (Vcc/Vdd) | 3 V ~ 5 V | |
Frequency - Switching | 200kHz ~ 1.4MHz | |
Duty Cycle (Max) | 95% | |
Synchronous Rectifier | Yes | |
Clock Sync | Yes | |
Serial Interfaces | I²C, PMBus, SMBus | |
Control Features | Current Limit, Enable, Power Good, Soft Start, Tracking | |
Operating Temperature | -40°C ~ 85°C (TA) | |
Package / Case | 36-VFQFN Exposed Pad | |
Supplier Device Package | 36-QFN (6x6) | |
Standard Package | 50 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ZL6105ALAF | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ZL6105ALAF is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ZL6105ALAF is new and unused, you can buy ZL6105ALAF Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ZL6105ALAF.
