XBP09-DMSIT-156

XBP09-DMSIT-156
Manufacturer Part Number:XBP09-DMSIT-156
Manufacturer:
Product Category:RF Transceiver Modules
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:RF TXRX MODULE ISM<1GHZ RP-SMA
Lead Free Status / RoHS Status:Contains lead / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):Obsolete / Discontinued
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: XBP09-DMSIT-156 Datasheet
XBP09-DMSIT-156´s Parameters
Internal Part Number898-XBP09-DMSIT-156
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Other Related DocumentsXBee™ Family Chart
Product Training ModulesMaximizing Range in Wireless Communications
Chat Session via XBee
Antenna Design and Integration Fundamentals
Video FileXBees Soar into Space on NASA Rocket
Which Mesh Networking Technology is Right for You?
RoHS InformationRoHS Declaration of Compliance
Design ResourcesDevelopment Tool Selector
IoT Product Selector
Featured ProductDigi International - The World of Xbee
PCN Obsolescence/ EOLXbee-Pro 900 Obs 11/Nov/2015
PCN Design/SpecificationRelease of XCTU 6.2 16/Jun/2015
XCTU 10/Jun/2016
CategoryRF/IF and RFID
FamilyRF Transceiver Modules
ManufacturerDigi International
SeriesXBee-PRO® DigiMesh 900
PackagingBulk
Part StatusObsolete
RF Family/StandardGeneral ISM < 1GHz
Protocol-
ModulationFHSS
Frequency900MHz
Data Rate156kbps
Power - Output17dBm
Sensitivity-100dBm
Serial InterfacesUART
Antenna TypeNot Included, RP-SMA
Memory Size-
Voltage - Supply3 V ~ 3.6 V
Current - Receiving80mA
Current - Transmitting210mA
Mounting TypeThrough Hole
Operating Temperature-40°C ~ 85°C
Package / CaseModule
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartXBP09-DMSIT-156
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

XBP09-DMSIT-156 is in stock for immediate shipping now. We are the distributor of Digi International all series components. The condition of XBP09-DMSIT-156 is new and unused, you can buy XBP09-DMSIT-156 Digi International with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for XBP09-DMSIT-156.
