Manufacturer Part Number: | WP1503EB/2YD |
---|---|
Manufacturer: | Kingbright |
Product Category: | LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs |
Available Quantity: | 9058 Pieces |
Unit Price: | Quote by Email |
Description: | LED Circuit Board Indicator 2 High Yellow (x 2) Diffused, Tinted 2.1V 20mA Round with Domed Top, 5mm (T-1 3/4) Through Hole, Right Angle |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | WP1503EB/2YD Datasheet |
Internal Part Number | 898-WP1503EB/2YD | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | WP1503EB/x.sldprt WP1503EB/x.pro WP1503EB/x.igs WP1503EB/x.stp | |
Online Catalog | Bi-Level 5mm Single Color Right Angle LEDs | |
Category | Optoelectronics | |
Family | LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs | |
Manufacturer | Kingbright | |
Series | - | |
Packaging | Bulk | |
Part Status | Active | |
Color | Yellow (x 2) | |
Wavelength - Peak | 590nm | |
Configuration | 2 High | |
Current | 20mA | |
Millicandela Rating | 30mcd | |
Viewing Angle | 60° | |
Lens Type | Diffused, Tinted | |
Lens Style/Size | Round with Domed Top, 5mm (T-1 3/4) | |
Voltage Rating | 2.1V | |
Mounting Type | Through Hole, Right Angle | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | WP1503EB/2YD | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
WP1503EB/2YD is in stock for immediate shipping now. We are the distributor of Kingbright all series components. The condition of WP1503EB/2YD is new and unused, you can buy WP1503EB/2YD Kingbright with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for WP1503EB/2YD.
