| Manufacturer Part Number: | WM1F068USA |
|---|---|
| Manufacturer: | JAE Electronics |
| Product Category: | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
| Available Quantity: | 9048 Pieces |
| Unit Price: | Quote by Email |
| Description: | 68 Position Connector Receptacle, Outer Shroud Contacts Through Hole Gold |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | WM1F068USA Datasheet |
| Internal Part Number | 898-WM1F068USA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | WM1 Series | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Manufacturer | JAE Electronics | |
| Series | WM1 | |
| Packaging | Tray | |
| Part Status | Active | |
| Connector Type | Receptacle, Outer Shroud Contacts | |
| Number of Positions | 68 | |
| Pitch | 0.039" (1.00mm) | |
| Number of Rows | 2 | |
| Mounting Type | Through Hole | |
| Features | Board Guide, Mating Guide | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Mated Stacking Heights | 12.8mm | |
| Height Above Board | 0.295" (7.50mm) | |
| Standard Package | 52 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | WM1F068USA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
WM1F068USA is in stock for immediate shipping now. We are the distributor of JAE Electronics all series components. The condition of WM1F068USA is new and unused, you can buy WM1F068USA JAE Electronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for WM1F068USA.
