Manufacturer Part Number: | W201132C205AQ |
---|---|
Manufacturer: | C&K Components |
Product Category: | Keylock Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Keylock Switch 2 Position DPDT 4A (AC) 125V (AC) Panel Mount |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | W201132C205AQ Datasheet |
Internal Part Number | 898-W201132C205AQ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Switches | |
Family | Keylock Switches | |
Manufacturer | C&K Components | |
Series | W | |
Part Status | Obsolete | |
Circuit | DPDT | |
Number of Positions | 2 | |
Switch Function | On-On | |
Contact Timing | Not Specified | |
Current Rating | 4A (AC) | |
Voltage Rating - AC | 125V | |
Voltage Rating - DC | - | |
Actuator Type | Flat Key | |
Key Removable Positions | 1 only | |
Angle of Throw | 90° | |
Contact Material | Copper | |
Contact Finish | Silver | |
Mounting Type | Panel Mount | |
Termination Style | Quick Connect - 0.110" (2.8mm) | |
Panel Cutout Dimensions | Circular - 19.30mm Dia | |
Features | - | |
Depth Behind Flange | 42.57mm | |
Operating Temperature | - | |
Mechanical Life | - | |
Electrical Life | 10,000 Cycles | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | W201132C205AQ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
W201132C205AQ is in stock for immediate shipping now. We are the distributor of C&K Components all series components. The condition of W201132C205AQ is new and unused, you can buy W201132C205AQ C&K Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for W201132C205AQ.
