Manufacturer Part Number: | VSK-S20-3R3U-T |
---|---|
Manufacturer: | CUI Inc. |
Product Category: | AC DC Converters |
Available Quantity: | 9104 Pieces |
Unit Price: | Quote by Email |
Description: | AC/DC CONVERTER 3.3V 20W |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | VSK-S20-3R3U-T Datasheet |
Internal Part Number | 898-VSK-S20-3R3U-T | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Encapsulated AC-DC Power Supply Series EMI Regulations and Mitigation Considerations for Switching Power Supplies Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks | |
RoHS Information | VSK-S20-T Series Cert of Compliance | |
3D Model | VSK-S20-3R3U-T | |
PCN Design/Specification | VSK-S1,VSK- S2 Series 15/Sep/2015 | |
Online Catalog | VSK-S20-T Series | |
Category | Power Supplies - External/Internal (Off-Board) | |
Family | AC DC Converters | |
Manufacturer | CUI Inc. | |
Series | VSK-S20-T | |
Part Status | Active | |
Type | Enclosed | |
Number of Outputs | 1 | |
Voltage - Input | 85 ~ 264 VAC | |
Voltage - Output 1 | 3.3V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Voltage - Output 4 | - | |
Current - Output (Max) | 4.1A | |
Power (Watts) | 20W | |
Applications | ITE (Commercial) | |
Voltage - Isolation | 3kV (3000V) | |
Efficiency | 73% | |
Operating Temperature | -40°C ~ 70°C | |
Features | Universal Input | |
Mounting Type | Chassis Mount | |
Size / Dimension | 3.78" L x 2.17" W x 1.26" H (96.1mm x 54.0mm x 32.0mm) | |
Minimum Load Required | - | |
Approvals | CE, cURus | |
Power (Watts) - Max | 14W | |
Standard Package | 24 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | VSK-S20-3R3U-T | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
VSK-S20-3R3U-T is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of VSK-S20-3R3U-T is new and unused, you can buy VSK-S20-3R3U-T CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VSK-S20-3R3U-T.
