Manufacturer Part Number: | VS-SD803C10S10C |
---|---|
Manufacturer: | Vishay BC Components |
Product Category: | Diodes - Rectifiers - Single |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Diode Standard 1000V (1kV) 845A Stud Mount B-43, Hockey PUK |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | VS-SD803C10S10C Datasheet |
Internal Part Number | 898-VS-SD803C10S10C | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Discrete Semiconductor Products | |
Family | Diodes - Rectifiers - Single | |
Manufacturer | Vishay Semiconductor Diodes Division | |
Series | - | |
Packaging | Bulk | |
Part Status | Active | |
Diode Type | Standard | |
Voltage - DC Reverse (Vr) (Max) | 1000V (1kV) | |
Current - Average Rectified (Io) | 845A | |
Voltage - Forward (Vf) (Max) @ If | 1.89V @ 2655A | |
Speed | Standard Recovery >500ns, > 200mA (Io) | |
Reverse Recovery Time (trr) | 1µs | |
Current - Reverse Leakage @ Vr | 45mA @ 1000V | |
Capacitance @ Vr, F | - | |
Mounting Type | Stud Mount | |
Package / Case | B-43, PUK | |
Supplier Device Package | B-43, Hockey PUK | |
Operating Temperature - Junction | * | |
Standard Package | 12 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | VS-SD803C10S10C | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
VS-SD803C10S10C is in stock for immediate shipping now. We are the distributor of Vishay BC Components all series components. The condition of VS-SD803C10S10C is new and unused, you can buy VS-SD803C10S10C Vishay BC Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VS-SD803C10S10C.
