| Manufacturer Part Number: | VN7020AJTR |
|---|---|
| Manufacturer: | STMicroelectronics |
| Product Category: | PMIC - Power Distribution Switches, Load Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC DRIVER HIGH SIDE POWERSSO16 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | VN7020AJTR Datasheet |
| Internal Part Number | 898-VN7020AJTR | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | AN1596 Appl Note | |
| Featured Product | VIPower™ M07 High-Side Driver | |
| Online Catalog | General Purpose | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Manufacturer | STMicroelectronics | |
| Series | VIPower™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 4 V ~ 28 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 45A | |
| Rds On (Typ) | 20 mOhm | |
| Input Type | Non-Inverting | |
| Features | Auto Restart, Status Flag | |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 16-PowerLFSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | PowerSSO-16 | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | VN7020AJTR | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
VN7020AJTR is in stock for immediate shipping now. We are the distributor of STMicroelectronics all series components. The condition of VN7020AJTR is new and unused, you can buy VN7020AJTR STMicroelectronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VN7020AJTR.
