VN101501

VN101501
Manufacturer Part Number:VN101501
Manufacturer:
Product Category:Magnetic Sensors - Position, Proximity, Speed (Modules)
Available Quantity:12746 Pieces
Unit Price:Quote by Email
Description:Magnetic Hall Effect Sensor Ferrous Vane Digital PC Pin Slotted Body
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: VN101501 Datasheet
VN101501´s Parameters
Internal Part Number898-VN101501
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog VN1015 Series
CategorySensors, Transducers
FamilyMagnetic Sensors - Position, Proximity, Speed (Modules)
ManufacturerCherry
Series-
Part StatusActive
Output TypeDigital
TypeHall Effect Sensor
Actuator MaterialFerrous Vane
Termination StylePC Pin
Frequency-
Voltage - Supply4.5 V ~ 24 V
Must Operate-
Must Release-
Operating Temperature-40°C ~ 85°C (TA)
Package / CaseSlotted Body
Standard Package 25
Weight0.001 KG
ApplicationEmail for details
Replacement PartVN101501
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

VN101501 is in stock for immediate shipping now. We are the distributor of Cherry all series components. The condition of VN101501 is new and unused, you can buy VN101501 Cherry with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for VN101501.
