| Manufacturer Part Number: | VMS-100-12 |
|---|---|
| Manufacturer: | CUI Inc. |
| Product Category: | AC DC Converters |
| Available Quantity: | 9044 Pieces |
| Unit Price: | Quote by Email |
| Description: | AC/DC CONVERTER 12V 100W |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | VMS-100-12 Datasheet |
| Internal Part Number | 898-VMS-100-12 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Density Medical Power Supplies-VMS Series Power Factor Correction in Ac-Dc Power Supplies EMI Regulations and Mitigation Considerations for Switching Power Supplies Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks | |
| Video File | CUI Medical Power Video | |
| RoHS Information | VMS-100 Series Cert of Compliance | |
| Featured Product | VMS Series | |
| 3D Model | VMS-100-12 | |
| Online Catalog | VMS-100 Series | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Manufacturer | CUI Inc. | |
| Series | VMS-100 | |
| Part Status | Active | |
| Type | Open Frame | |
| Number of Outputs | 1 | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 8.4A | |
| Power (Watts) | 100W | |
| Applications | Medical | |
| Voltage - Isolation | 5.656kV (5656V) | |
| Efficiency | 89% | |
| Operating Temperature | -25°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, PFC, Remote Sense, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 5.00" L x 3.00" W x 1.05" H (127.0mm x 76.2mm x 26.7mm) | |
| Minimum Load Required | No | |
| Approvals | CE, cURus, GS | |
| Power (Watts) - Max | 100W | |
| Standard Package | 50 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | VMS-100-12 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
VMS-100-12 is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of VMS-100-12 is new and unused, you can buy VMS-100-12 CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VMS-100-12.
