Manufacturer Part Number: | VK204-25-E |
---|---|
Manufacturer: | Matrix Orbital |
Product Category: | Display Modules - Vacuum Fluorescent (VFD) |
Available Quantity: | 9012 Pieces |
Unit Price: | Quote by Email |
Description: | Vacuum Fluorescent Display (VFD) 20 x 4 Character 9 V ~ 15 V Serial 98.00mm x 60.00mm x 27.70mm |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | VK204-25-E Datasheet |
Internal Part Number | 898-VK204-25-E | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Design/Specification | VK204-25 Series Update 03/Mar/2010 12C Displays Firmware Update 11/Oct/2011 | |
Category | Optoelectronics | |
Family | Display Modules - Vacuum Fluorescent (VFD) | |
Manufacturer | Matrix Orbital | |
Series | VK204-25 | |
Part Status | Active | |
Outline L x W x H | 98.00mm x 60.00mm x 27.70mm | |
Viewing Area | 70.80mm L x 20.90mm W | |
Display Format | 20 x 4 | |
Display Type | Character | |
Format | 5 x 7 Dots | |
Voltage - Supply | 9 V ~ 15 V | |
Character Size | 4.70mm H x 2.40mm W | |
Number of Dots | - | |
Interface | Serial | |
Operating Temperature | -40°C ~ 85°C | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | VK204-25-E | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
VK204-25-E is in stock for immediate shipping now. We are the distributor of Matrix Orbital all series components. The condition of VK204-25-E is new and unused, you can buy VK204-25-E Matrix Orbital with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VK204-25-E.
