| Manufacturer Part Number: | VK202-25 |
|---|---|
| Manufacturer: | Matrix Orbital |
| Product Category: | Display Modules - Vacuum Fluorescent (VFD) |
| Available Quantity: | 9093 Pieces |
| Unit Price: | Quote by Email |
| Description: | Vacuum Fluorescent Display (VFD) 20 x 2 Character Serial 116.00mm x 37.00mm x 29.48mm |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | VK202-25 Datasheet |
| Internal Part Number | 898-VK202-25 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | VK202-25 Screen Board 10/Nov/2009 VFD Display Update 22/Oct/2013 | |
| Online Catalog | VK202-25 Series | |
| Category | Optoelectronics | |
| Family | Display Modules - Vacuum Fluorescent (VFD) | |
| Manufacturer | Matrix Orbital | |
| Series | VK202-25 | |
| Part Status | Active | |
| Outline L x W x H | 116.00mm x 37.00mm x 29.48mm | |
| Viewing Area | 89.75mm L x 11.50mm W | |
| Display Format | 20 x 2 | |
| Display Type | Character | |
| Format | 5 x 7 Dots | |
| Voltage - Supply | - | |
| Character Size | 4.70mm H x 2.40mm W | |
| Number of Dots | - | |
| Interface | Serial | |
| Operating Temperature | -20°C ~ 70°C | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | VK202-25 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
VK202-25 is in stock for immediate shipping now. We are the distributor of Matrix Orbital all series components. The condition of VK202-25 is new and unused, you can buy VK202-25 Matrix Orbital with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VK202-25.
