Manufacturer Part Number: | VC-TXO-23SM-196.8-B |
---|---|
Manufacturer: | ECS Inc. |
Product Category: | Oscillators |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 19.68MHz Clipped Sine Wave VCTCXO Oscillator Surface Mount 3V 1.5mA |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | VC-TXO-23SM-196.8-B Datasheet |
Internal Part Number | 898-VC-TXO-23SM-196.8-B | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Crystals and Oscillators | |
Family | Oscillators | |
Manufacturer | ECS Inc. | |
Series | VC-TXO-23SM | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | VCTCXO | |
Frequency | 19.68MHz | |
Function | - | |
Output | Clipped Sine Wave | |
Voltage - Supply | 3V | |
Frequency Stability | ±2.5ppm | |
Operating Temperature | -30°C ~ 75°C | |
Current - Supply (Max) | 1.5mA | |
Ratings | - | |
Mounting Type | Surface Mount | |
Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) | |
Height | 0.039" (1.00mm) | |
Package / Case | 4-SMD, No Lead (DFN, LCC) | |
Current - Supply (Disable) (Max) | - | |
Standard Package | 1,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | VC-TXO-23SM-196.8-B | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
VC-TXO-23SM-196.8-B is in stock for immediate shipping now. We are the distributor of ECS Inc. all series components. The condition of VC-TXO-23SM-196.8-B is new and unused, you can buy VC-TXO-23SM-196.8-B ECS Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VC-TXO-23SM-196.8-B.
