Manufacturer Part Number: | V1D1S00B-00000-000 |
---|---|
Manufacturer: | Carling Technologies |
Product Category: | Rocker Switches |
Available Quantity: | 9054 Pieces |
Unit Price: | Quote by Email |
Description: | Rocker Switch SPST 20A (DC) Panel Mount, Snap-In |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | V1D1S00B-00000-000 Datasheet |
Internal Part Number | 898-V1D1S00B-00000-000 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | V Series | |
Category | Switches | |
Family | Rocker Switches | |
Manufacturer | Carling Technologies | |
Series | V | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | SPST | |
Switch Function | On-Off | |
Current Rating | 20A (DC) | |
Voltage Rating - AC | - | |
Voltage Rating - DC | 12V | |
Actuator Type | Actuator Arm, Cap Required | |
Color - Actuator/Cap | - | |
Actuator Marking | Varies by Cap | |
Illumination Type, Color | - | |
Illumination Voltage (Nominal) | - | |
Mounting Type | Panel Mount, Snap-In | |
Termination Style | Quick Connect - 0.250" (6.3mm) | |
Ingress Protection | IP66/68 - Dust Tight, Water Resistant, Waterproof | |
Features | - | |
Panel Cutout Dimensions | Rectangular - 36.83mm x 21.08mm | |
Operating Temperature | -40°C ~ 85°C | |
Mechanical Life | 150,000 Cycles | |
Electrical Life | 50,000 Cycles | |
Standard Package | 100 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | V1D1S00B-00000-000 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
V1D1S00B-00000-000 is in stock for immediate shipping now. We are the distributor of Carling Technologies all series components. The condition of V1D1S00B-00000-000 is new and unused, you can buy V1D1S00B-00000-000 Carling Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for V1D1S00B-00000-000.
