| Manufacturer Part Number: | UEZGUI-1788-70WVT-BA |
|---|---|
| Manufacturer: | Future Designs Inc. |
| Product Category: | Display Modules - LCD, OLED, Graphic |
| Available Quantity: | 9039 Pieces |
| Unit Price: | Quote by Email |
| Description: | Resistive Graphic LCD Display Module Transmissive Red, Green, Blue (RGB) TFT - Color I²C, SPI 7" (177.80mm) 800 x 480 (WVGA) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | UEZGUI-1788-70WVT-BA Datasheet |
| Internal Part Number | 898-UEZGUI-1788-70WVT-BA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | µEZ GUI | |
| Featured Product | 7.0" Resistive Touchscreen LCD GUI | |
| PCN Design/Specification | LCD Power Update 20/Apr/2015 | |
| Online Catalog | LPC1788 Board Assembly 7.0" Resistive Touch Screen | |
| Category | Optoelectronics | |
| Family | Display Modules - LCD, OLED, Graphic | |
| Manufacturer | Future Designs Inc. | |
| Series | uEZ® GUI | |
| Part Status | Active | |
| Display Type | TFT - Color | |
| Display Mode | Transmissive | |
| Touchscreen | Resistive | |
| Diagonal Screen Size | 7" (177.80mm) | |
| Viewing Area | 154.18mm W x 85.85mm H | |
| Backlight | LED - White | |
| Dot Pixels | 800 x 480 (WVGA) | |
| Interface | I²C, SPI | |
| Graphics Color | Red, Green, Blue (RGB) | |
| Background Color | - | |
| Dot Size | - | |
| Dot Pitch | - | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | UEZGUI-1788-70WVT-BA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
UEZGUI-1788-70WVT-BA is in stock for immediate shipping now. We are the distributor of Future Designs Inc. all series components. The condition of UEZGUI-1788-70WVT-BA is new and unused, you can buy UEZGUI-1788-70WVT-BA Future Designs Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for UEZGUI-1788-70WVT-BA.
