| Manufacturer Part Number: | TR2-S505H-V-1.6-R |
|---|---|
| Manufacturer: | Eaton |
| Product Category: | Fuses |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | FUSE CERAMIC 1.6A 600VAC 400VDC |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | TR2-S505H-V-1.6-R Datasheet |
| Internal Part Number | 898-TR2-S505H-V-1.6-R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Circuit Protection | |
| Family | Fuses | |
| Manufacturer | Eaton | |
| Series | S505H | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Fuse Type | Cartridge, Ceramic | |
| Current Rating | 1.6A | |
| Voltage Rating - AC | 600V | |
| Voltage Rating - DC | 400V | |
| Response Time | Slow | |
| Package / Case | 5mm x 20mm (Axial) | |
| Mounting Type | Through Hole | |
| Breaking Capacity @ Rated Voltage | 1.5kA | |
| Melting I²t | 6.78 | |
| Approvals | cULus, PSE/JET | |
| Operating Temperature | -40°C ~ 85°C | |
| Color | - | |
| Size / Dimension | 0.218" Dia x 0.831" L (5.54mm x 21.10mm) | |
| DC Cold Resistance | 0.07 Ohm | |
| Standard Package | 1,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | TR2-S505H-V-1.6-R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
TR2-S505H-V-1.6-R is in stock for immediate shipping now. We are the distributor of Eaton all series components. The condition of TR2-S505H-V-1.6-R is new and unused, you can buy TR2-S505H-V-1.6-R Eaton with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TR2-S505H-V-1.6-R.
