Manufacturer Part Number: | TPS82740BSIPT |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | DC DC Converters |
Available Quantity: | 11260 Pieces |
Unit Price: | Quote by Email |
Description: | DC/DC CONVERTER 2.6-3.3V 0.66W |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 2 (1 Year) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TPS82740BSIPT Datasheet |
Internal Part Number | 898-TPS82740BSIPT | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | TPS82740B Design with WEBENCH® Power Designer | |
Featured Product | TPS82740A MicroSiP™ Module | |
Reference Design Library | TPS82740BEVM-617: 2.2 ~ 3.3V @ 0.2A, 2.2 ~ 5.5V in | |
Manufacturer Product Page | TPS82740BSIPT Specifications | |
Online Catalog | TPS82740x | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | Texas Instruments | |
Series | MicroSip™ | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Non-Isolated PoL Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 2.2V | |
Voltage - Input (Max) | 5.5V | |
Voltage - Output 1 | 2.6 ~ 3.3 V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 200mA | |
Power (Watts) - Manufacture Series | - | |
Voltage - Isolation | - | |
Applications | ITE (Commercial) | |
Features | Remote On/Off, OCP, UVLO | |
Mounting Type | Surface Mount | |
Package / Case | 9-BGA | |
Size / Dimension | 0.12" L x 0.09" W x 0.04" H (3.0mm x 2.4mm x 1.0mm) | |
Operating Temperature | -40°C ~ 85°C | |
Efficiency | 90% | |
Power (Watts) - Max | - | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TPS82740BSIPT | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TPS82740BSIPT is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of TPS82740BSIPT is new and unused, you can buy TPS82740BSIPT Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TPS82740BSIPT.
