| Manufacturer Part Number: | TPS63020QDSJRQ1 |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | PMIC - Voltage Regulators - DC DC Switching Regulators |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Buck-Boost Switching Regulator IC Positive Adjustable 1.2V 1 Output 3.5A (Switch) 14-VFDFN Exposed Pad |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | TPS63020QDSJRQ1 Datasheet |
| Internal Part Number | 898-TPS63020QDSJRQ1 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | TPS63020-Q1 Pin FMEA | |
| PCN Design/Specification | Data Sheet Chg 09/Feb/2016 | |
| Manufacturer Product Page | TPS63020QDSJRQ1 Specifications | |
| Online Catalog | Buck-Boost IC | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Manufacturer | Texas Instruments | |
| Series | Automotive, AEC-Q100 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Function | Step-Up/Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck-Boost | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 1.8V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output (Min/Fixed) | 1.2V | |
| Voltage - Output (Max) | 5.5V | |
| Current - Output | 3.5A (Switch) | |
| Frequency - Switching | 2.4MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-VFDFN Exposed Pad | |
| Supplier Device Package | 14-VSON (4x3) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | TPS63020QDSJRQ1 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
TPS63020QDSJRQ1 is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of TPS63020QDSJRQ1 is new and unused, you can buy TPS63020QDSJRQ1 Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TPS63020QDSJRQ1.
