| Manufacturer Part Number: | TPD13S523RSVR |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | TVS - Mixed Technology |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | TVS DIODE 5.5VWM 15VC 16UQFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | TPD13S523RSVR Datasheet |
| Internal Part Number | 898-TPD13S523RSVR | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | ESD Protection Basics | |
| PCN Assembly/Origin | Assembly Site 05/Feb/2016 | |
| Manufacturer Product Page | TPD13S523RSVR Specifications | |
| Online Catalog | TPD13S523 Series | |
| Category | Circuit Protection | |
| Family | TVS - Mixed Technology | |
| Manufacturer | Texas Instruments | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Voltage - Working | 5.5V | |
| Voltage - Clamping | 15V | |
| Technology | Diode Array | |
| Power (Watts) | 30W | |
| Number of Circuits | 13 | |
| Applications | General Purpose | |
| Package / Case | 16-WFQFN | |
| Supplier Device Package | 16-UQFN (2.6x1.8) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | TPD13S523RSVR | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
TPD13S523RSVR is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of TPD13S523RSVR is new and unused, you can buy TPD13S523RSVR Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TPD13S523RSVR.
