| Manufacturer Part Number: | TOP267VG |
|---|---|
| Manufacturer: | Power Integrations |
| Product Category: | PMIC - AC DC Converters, Offline Switchers |
| Available Quantity: | 9025 Pieces |
| Unit Price: | Quote by Email |
| Description: | Converter Offline Flyback Topology 66kHz, 132kHz eDIP-12 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | TOP267VG Datasheet |
| Internal Part Number | 898-TOP267VG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | TopSwitch JX Integrated Switcher ICs | |
| PCN Design/Specification | Design Chgs 29/Jul/2016 | |
| PCN Assembly/Origin | HALT 26/Jan/2016 Alt Assembly Site 29/Apr/2016 | |
| PCN Packaging | Multiple Devices 15/Mar/2011 | |
| Online Catalog | AC DC Converters, Offline Switchers | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - AC DC Converters, Offline Switchers | |
| Manufacturer | Power Integrations | |
| Series | TOPSwitch®-JX | |
| Packaging | Tube | |
| Part Status | Active | |
| Output Isolation | Isolated | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 725V | |
| Topology | Flyback | |
| Voltage - Start Up | - | |
| Voltage - Supply (Vcc/Vdd) | - | |
| Duty Cycle | 78% | |
| Frequency - Switching | 66kHz, 132kHz | |
| Power (Watts) | 44W | |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit | |
| Control Features | Frequency Control | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 12-SDIP (0.412", 10.46mm) Exposed Pad | |
| Supplier Device Package | eDIP-12 | |
| Mounting Type | Through Hole | |
| Standard Package | 48 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | TOP267VG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
TOP267VG is in stock for immediate shipping now. We are the distributor of Power Integrations all series components. The condition of TOP267VG is new and unused, you can buy TOP267VG Power Integrations with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TOP267VG.
