Manufacturer Part Number: | TMPSNSRD-RTD2 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - Sensors |
Available Quantity: | 9016 Pieces |
Unit Price: | Quote by Email |
Description: | MCP3551, MCP9804 - Temperature Sensor Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TMPSNSRD-RTD2 Datasheet |
Internal Part Number | 898-TMPSNSRD-RTD2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | MCP3901 Analog Front End | |
Software Download | Thermal Management Utility v1.3.2 | |
Design Resources | Development Tool Selector | |
Reference Design Library | TMPSNSRD-RTD2: RTD w/ 22bit ADC, USB Interface | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | MCP3551 and MCP9804 RTD Reference Design Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - Sensors | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Sensor Type | Temperature | |
Sensing Range | - | |
Interface | USB | |
Sensitivity | - | |
Voltage - Supply | - | |
Embedded | No | |
Supplied Contents | Board, Cable | |
Utilized IC / Part | MCP3551, MCP9804 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TMPSNSRD-RTD2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TMPSNSRD-RTD2 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of TMPSNSRD-RTD2 is new and unused, you can buy TMPSNSRD-RTD2 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TMPSNSRD-RTD2.
