Manufacturer Part Number: | TF2527VU-102Y3R0-01 |
---|---|
Manufacturer: | TDK Corporation |
Product Category: | Common Mode Chokes |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 2 Line Common Mode Choke Through Hole 3A DCR 90 Ohm |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TF2527VU-102Y3R0-01 Datasheet |
Internal Part Number | 898-TF2527VU-102Y3R0-01 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Filters | |
Family | Common Mode Chokes | |
Manufacturer | TDK Corporation | |
Series | TF | |
Packaging | Bulk | |
Part Status | Obsolete | |
Filter Type | Power Line | |
Number of Lines | 2 | |
Impedance @ Frequency | - | |
Inductance @ Frequency | - | |
Current Rating (Max) | 3A | |
DC Resistance (DCR) (Max) | 90 Ohm | |
Voltage Rating - DC | - | |
Voltage Rating - AC | - | |
Operating Temperature | -20°C ~ 120°C | |
Ratings | - | |
Approvals | - | |
Features | - | |
Mounting Type | Through Hole | |
Size / Dimension | 0.984" L x 0.787" W (25.00mm x 20.00mm) | |
Height (Max) | 1.063" (27.00mm) | |
Package / Case | Vertical, 4 PC Pin | |
Standard Package | 10 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TF2527VU-102Y3R0-01 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TF2527VU-102Y3R0-01 is in stock for immediate shipping now. We are the distributor of TDK Corporation all series components. The condition of TF2527VU-102Y3R0-01 is new and unused, you can buy TF2527VU-102Y3R0-01 TDK Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TF2527VU-102Y3R0-01.
