Manufacturer Part Number: | TDGL006 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9017 Pieces |
Unit Price: | Quote by Email |
Description: | LAN8720 - Interface, Network Shield Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TDGL006 Datasheet |
Internal Part Number | 898-TDGL006 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | ChipKIT Network Shield Schematics Development Tool Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | chipKIT™ Network Shield TDGL006 | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | Interface, Network Shield | |
Embedded | - | |
Utilized IC / Part | LAN8720 | |
Primary Attributes | 10/100 Ethernet, USB Host Device | |
Secondary Attributes | - | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TDGL006 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TDGL006 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of TDGL006 is new and unused, you can buy TDGL006 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TDGL006.
