Manufacturer Part Number: | TCF30 |
---|---|
Manufacturer: | Eaton |
Product Category: | Electrical, Specialty Fuses |
Available Quantity: | 9031 Pieces |
Unit Price: | Quote by Email |
Description: | FUSE RECT 30A 600VAC/300DC BLADE |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TCF30 Datasheet |
Internal Part Number | 898-TCF30 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | CUBEFuse® TCF Series | |
Category | Circuit Protection | |
Family | Electrical, Specialty Fuses | |
Manufacturer | Eaton | |
Series | CUBEFuse™ TCF | |
Packaging | Bulk | |
Part Status | Active | |
Fuse Type | Rectangular | |
Current Rating | 30A | |
Voltage Rating - AC | 600V | |
Voltage Rating - DC | 300V | |
Response Time | Slow | |
Applications | Electrical, Industrial | |
Features | Indicating | |
Class | - | |
Approvals | CE, CSA, UL | |
Operating Temperature | -40°C ~ 80°C | |
Breaking Capacity @ Rated Voltage | 300kA AC, 100kA DC | |
Mounting Type | Holder | |
Package / Case | Blade Type, Module | |
Size / Dimension | 1.880" L x 0.750" W x 1.270" H (47.75mm x 19.05mm x 32.26mm) | |
Melting I²t | - | |
DC Cold Resistance | - | |
Standard Package | 12 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TCF30 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TCF30 is in stock for immediate shipping now. We are the distributor of Eaton all series components. The condition of TCF30 is new and unused, you can buy TCF30 Eaton with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TCF30.
