| Manufacturer Part Number: | STW75NF30 |
|---|---|
| Manufacturer: | STMicroelectronics |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 10315 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET N-CH 300V 60A TO-247 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | STW75NF30 Datasheet |
| Internal Part Number | 898-STW75NF30 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | STW75NF30 View All Specifications | |
| Product Training Modules | Automotive Grade Transistors and Discretes | |
| Online Catalog | N-Channel Standard FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | STMicroelectronics | |
| Series | STripFET™ | |
| Packaging | Tube | |
| Part Status | Active | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 300V | |
| Current - Continuous Drain (Id) @ 25°C | 60A (Tc) | |
| Rds On (Max) @ Id, Vgs | 45 mOhm @ 30A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 164nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 5930pF @ 25V | |
| Power - Max | 320W | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | TO-247-3 | |
| Supplier Device Package | TO-247-3 | |
| Standard Package | 30 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | STW75NF30 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
STW75NF30 is in stock for immediate shipping now. We are the distributor of STMicroelectronics all series components. The condition of STW75NF30 is new and unused, you can buy STW75NF30 STMicroelectronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for STW75NF30.
