| Manufacturer Part Number: | STGIPS20C60 |
|---|---|
| Manufacturer: | STMicroelectronics |
| Product Category: | Power Driver Modules |
| Available Quantity: | 9052 Pieces |
| Unit Price: | Quote by Email |
| Description: | Power Driver Module IGBT 3 Phase 600V 20A 25-DIP Module |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | STGIPS20C60 Datasheet |
| Internal Part Number | 898-STGIPS20C60 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | IGBT and SLLIMM IPM | |
| Online Catalog | SLLIMM™ Series | |
| Category | Discrete Semiconductor Products | |
| Family | Power Driver Modules | |
| Manufacturer | STMicroelectronics | |
| Series | SLLIMM™ | |
| Part Status | Active | |
| Type | IGBT | |
| Configuration | 3 Phase | |
| Current | 20A | |
| Voltage | 600V | |
| Voltage - Isolation | 2500Vrms | |
| Package / Case | 25-DIP Module | |
| Standard Package | 11 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | STGIPS20C60 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
STGIPS20C60 is in stock for immediate shipping now. We are the distributor of STMicroelectronics all series components. The condition of STGIPS20C60 is new and unused, you can buy STGIPS20C60 STMicroelectronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for STGIPS20C60.
