| Manufacturer Part Number: | SST-90-G-F11-JH201 |
|---|---|
| Manufacturer: | Luminus Devices Inc. |
| Product Category: | LED Lighting - COBs, Engines, Modules |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LED Lighting COBs, Engines, Modules Chip On Board (COB) SST-90 Green Square |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 2A (4 Weeks) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | SST-90-G-F11-JH201 Datasheet |
| Internal Part Number | 898-SST-90-G-F11-JH201 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| PCN Obsolescence/ EOL | SST/SSR-90-B/G Devices 17/Jun/2014 | |
| Category | Optoelectronics | |
| Family | LED Lighting - COBs, Engines, Modules | |
| Manufacturer | Luminus Devices Inc. | |
| Series | SST-90 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Type | Chip On Board (COB) | |
| Color | Green | |
| CCT (K) | - | |
| Wavelength | 537nm | |
| Configuration | Square | |
| Flux @ Current/Temperature - Test | 855 lm (Typ) | |
| Current - Test | 3.15A | |
| Temperature - Test | 25°C | |
| Voltage - Forward (Vf) (Typ) | 3.4V | |
| Lumens/Watt @ Current - Test | 80 lm/W | |
| Current - Max | 27A | |
| CRI (Color Rendering Index) | 70 | |
| Viewing Angle | 100° | |
| Features | - | |
| Size / Dimension | 11.00mm L x 10.00mm W | |
| Height | 5.40mm | |
| Light Emitting Surface (LES) | 8.00mm Diameter | |
| Lens Type | Domed | |
| Standard Package | 25 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | SST-90-G-F11-JH201 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
SST-90-G-F11-JH201 is in stock for immediate shipping now. We are the distributor of Luminus Devices Inc. all series components. The condition of SST-90-G-F11-JH201 is new and unused, you can buy SST-90-G-F11-JH201 Luminus Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SST-90-G-F11-JH201.
