Manufacturer Part Number: | SRP7030-1R1FM |
---|---|
Manufacturer: | Bourns Inc. |
Product Category: | Fixed Inductors |
Available Quantity: | 10779 Pieces |
Unit Price: | Quote by Email |
Description: | 1.1µH Shielded Wirewound Inductor 11A 7 mOhm Max Nonstandard |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | SRP7030-1R1FM Datasheet |
Internal Part Number | 898-SRP7030-1R1FM | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | SRP7030F Series Material Declaration | |
3D Model | SRP7030.stp | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | SRP Series | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | Bourns Inc. | |
Series | SRP7030F | |
Packaging | Digi-Reel® | |
Part Status | Active | |
Type | Wirewound | |
Material - Core | Iron | |
Inductance | 1.1µH | |
Tolerance | ±20% | |
Current Rating | 11A | |
Current - Saturation | 13A | |
Shielding | Shielded | |
DC Resistance (DCR) | 7 mOhm Max | |
Q @ Freq | - | |
Frequency - Self Resonant | - | |
Ratings | - | |
Operating Temperature | -55°C ~ 125°C | |
Frequency - Test | 100kHz | |
Mounting Type | Surface Mount | |
Package / Case | Nonstandard | |
Size / Dimension | 0.299" L x 0.256" W (7.60mm x 6.50mm) | |
Height - Seated (Max) | 0.118" (3.00mm) | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | SRP7030-1R1FM | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
SRP7030-1R1FM is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of SRP7030-1R1FM is new and unused, you can buy SRP7030-1R1FM Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SRP7030-1R1FM.
