Manufacturer Part Number: | SRP1045-3R2M |
---|---|
Manufacturer: | Bourns Inc. |
Product Category: | Fixed Inductors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 3.2µH Shielded Wirewound Inductor 8A 10.4 mOhm Max Nonstandard |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | SRP1045-3R2M Datasheet |
Internal Part Number | 898-SRP1045-3R2M | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | SRP1045 Series Material Declaration | |
3D Model | SRP1045.stp | |
PCN Assembly/Origin | Magnetic products Oct/2013 | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | Bourns Inc. | |
Series | SRP1045 | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Wirewound | |
Material - Core | Ferrite | |
Inductance | 3.2µH | |
Tolerance | ±20% | |
Current Rating | 8A | |
Current - Saturation | 8A | |
Shielding | Shielded | |
DC Resistance (DCR) | 10.4 mOhm Max | |
Q @ Freq | - | |
Frequency - Self Resonant | - | |
Ratings | - | |
Operating Temperature | -55°C ~ 150°C | |
Frequency - Test | 100kHz | |
Mounting Type | Surface Mount | |
Package / Case | Nonstandard | |
Size / Dimension | 0.422" L x 0.368" W (11.00mm x 9.35mm) | |
Height - Seated (Max) | 0.189" (4.80mm) | |
Standard Package | 600 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | SRP1045-3R2M | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
SRP1045-3R2M is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of SRP1045-3R2M is new and unused, you can buy SRP1045-3R2M Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SRP1045-3R2M.
