| Manufacturer Part Number: | SMT40C2-00SADJJ |
|---|---|
| Manufacturer: | Artesyn Embedded Technologies |
| Product Category: | DC DC Converters |
| Available Quantity: | 9570 Pieces |
| Unit Price: | Quote by Email |
| Description: | CONV DC/DC 200W 0.6-5V@40A SMD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | SMT40C2-00SADJJ Datasheet |
| Internal Part Number | 898-SMT40C2-00SADJJ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Declaration of Conformity | |
| Featured Product | SMT40C2 Series Converter | |
| PCN Packaging | CSA Marking 20/Sep/2013 | |
| Online Catalog | SIL40C2 and SMT40C2 Series | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Manufacturer | Artesyn Embedded Technologies | |
| Series | SMT40C2 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 13.8V | |
| Voltage - Output 1 | 0.6 ~ 5 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 40A | |
| Power (Watts) - Manufacture Series | 200W | |
| Voltage - Isolation | - | |
| Applications | ITE (Commercial) | |
| Features | Remote On/Off, OVP, SCP | |
| Mounting Type | Surface Mount | |
| Package / Case | Module | |
| Size / Dimension | 1.20" L x 1.10" W x 0.44" H (30.5mm x 27.9mm x 11.2mm) | |
| Operating Temperature | 0°C ~ 70°C | |
| Efficiency | 94% | |
| Power (Watts) - Max | 200W | |
| Standard Package | 140 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | SMT40C2-00SADJJ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
SMT40C2-00SADJJ is in stock for immediate shipping now. We are the distributor of Artesyn Embedded Technologies all series components. The condition of SMT40C2-00SADJJ is new and unused, you can buy SMT40C2-00SADJJ Artesyn Embedded Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SMT40C2-00SADJJ.
