| Manufacturer Part Number: | SG2013J-883B |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Transistors - Bipolar (BJT) - Arrays |
| Available Quantity: | 9110 Pieces |
| Unit Price: | Quote by Email |
| Description: | TRANS 7NPN DARL 50V 0.6A 16JDIP |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | SG2013J-883B Datasheet |
| Internal Part Number | 898-SG2013J-883B | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | High-Reliability Semiconductors | |
| Online Catalog | NPN Transistor Arrays | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - Bipolar (BJT) - Arrays | |
| Manufacturer | Microsemi IRE Division | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Quote Required | |
| Transistor Type | 7 NPN Darlington | |
| Current - Collector (Ic) (Max) | 600mA | |
| Voltage - Collector Emitter Breakdown (Max) | 50V | |
| Vce Saturation (Max) @ Ib, Ic | 1.9V @ 600µA, 500mA | |
| Current - Collector Cutoff (Max) | - | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 900 @ 500mA, 2V | |
| Power - Max | - | |
| Frequency - Transition | - | |
| Mounting Type | Through Hole | |
| Package / Case | - | |
| Supplier Device Package | 16-CDIP | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | SG2013J-883B | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
SG2013J-883B is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of SG2013J-883B is new and unused, you can buy SG2013J-883B Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SG2013J-883B.
