| Manufacturer Part Number: | SG-710ECK 1.8432MC |
|---|---|
| Manufacturer: | EPSON |
| Product Category: | Oscillators |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 1.8432MHz CMOS XO (Standard) Oscillator Surface Mount 3.3V 8mA Standby (Power Down) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | SG-710ECK 1.8432MC Datasheet |
| Internal Part Number | 898-SG-710ECK 1.8432MC | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | SPXO and VCXO | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Aug/2015 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Manufacturer | EPSON | |
| Series | SG-710 | |
| Packaging | Bulk | |
| Part Status | Obsolete | |
| Type | XO (Standard) | |
| Frequency | 1.8432MHz | |
| Function | Standby (Power Down) | |
| Output | CMOS | |
| Voltage - Supply | 3.3V | |
| Frequency Stability | ±100ppm | |
| Operating Temperature | -10°C ~ 70°C | |
| Current - Supply (Max) | 8mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.287" L x 0.189" W (7.30mm x 4.80mm) | |
| Height | 0.055" (1.40mm) | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | 13µA | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | SG-710ECK 1.8432MC | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
SG-710ECK 1.8432MC is in stock for immediate shipping now. We are the distributor of EPSON all series components. The condition of SG-710ECK 1.8432MC is new and unused, you can buy SG-710ECK 1.8432MC EPSON with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SG-710ECK 1.8432MC.
