SDEB-9P(55)

SDEB-9P(55)
Manufacturer Part Number:SDEB-9P(55)
Manufacturer:
Product Category:D-Sub Connectors
Available Quantity:9020 Pieces
Unit Price:Quote by Email
Description:9 Position D-Sub Plug, Male Pins Connector, Through Hole Solder
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: SDEB-9P(55) Datasheet
SDEB-9P(55)´s Parameters
Internal Part Number898-SDEB-9P(55)
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog SD Series
CategoryConnectors, Interconnects
FamilyD-Sub Connectors
ManufacturerHirose Electric Co Ltd
SeriesSD
PackagingTray
Part StatusActive
Connector StyleD-Sub
Connector TypePlug, Male Pins
Number of Positions9
Number of Rows2
Shell Size, Connector Layout1 (DE, E)
Contact TypeSignal
Mounting TypeThrough Hole
Flange FeatureHousing/Shell (Unthreaded)
TerminationSolder
Features-
Shell Material, FinishSteel, Nickel Plated
Contact FinishGold
Contact Finish Thickness8µin (0.20µm)
Ingress Protection-
Operating Temperature-
Voltage Rating350V
Current Rating3A
Housing MaterialPolybutylene Terephthalate (PBT)
ColorBlack
Standard Package 10
Weight0.001 KG
ApplicationEmail for details
Replacement PartSDEB-9P(55)
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

SDEB-9P(55) is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of SDEB-9P(55) is new and unused, you can buy SDEB-9P(55) Hirose Electric Co Ltd with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for SDEB-9P(55).
