SD-2031

SD-2031
Manufacturer Part Number:SD-2031
Manufacturer:
Product Category:DIP Switches
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:Dip Switch BCD Complement 10 Position Through Hole, Right Angle Rotary for Tool Actuator 100mA 5VDC
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: SD-2031 Datasheet
SD-2031´s Parameters
Internal Part Number898-SD-2031
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Product Training Modules3D CAD Models
3D ModelSD-2031
CategorySwitches
FamilyDIP Switches
ManufacturerCopal Electronics Inc.
SeriesSD-2000
PackagingBulk
Part StatusActive
CircuitBCD Complement
Number of Positions10
Current Rating100mA
Voltage Rating5VDC
Actuator TypeRotary for Tool
Actuator LevelFlush, Recessed
Contact MaterialCopper Alloy
Contact FinishGold
Height Above Board0.394" (10.00mm)
Mounting TypeThrough Hole, Right Angle
Termination StylePC Pin
Pitch0.100" (2.54mm), Full
WashableNo
Features-
Body MaterialPolyphenylene Sulfide (PPS)
Length0.393" (10.00mm)
Operating Temperature-40°C ~ 85°C
Mechanical Life-
Electrical Life20,000 Steps
Standard Package 100
Weight0.001 KG
ApplicationEmail for details
Replacement PartSD-2031
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

SD-2031 is in stock for immediate shipping now. We are the distributor of Copal Electronics Inc. all series components. The condition of SD-2031 is new and unused, you can buy SD-2031 Copal Electronics Inc. with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for SD-2031.
