Manufacturer Part Number: | SC8673010L |
---|---|
Manufacturer: | Panasonic Electronic Components |
Product Category: | Transistors - FETs, MOSFETs - Arrays |
Available Quantity: | 12010 Pieces |
Unit Price: | Quote by Email |
Description: | MOSFET 2N-CH 30V 16A/40A 8-HSO |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | SC8673010L Datasheet |
Internal Part Number | 898-SC8673010L | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Featured Product | SK8/SC8 Series - Single and Dual Type N Power MOSFET Wearables Technology Components | |
Online Catalog | N-Channel Logic Level Gate FETs | |
Category | Discrete Semiconductor Products | |
Family | Transistors - FETs, MOSFETs - Arrays | |
Manufacturer | Panasonic Electronic Components | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
FET Type | 2 N-Channel (Dual) Asymmetrical | |
FET Feature | Logic Level Gate | |
Drain to Source Voltage (Vdss) | 30V | |
Current - Continuous Drain (Id) @ 25°C | 16A, 40A | |
Rds On (Max) @ Id, Vgs | 10 mOhm @ 8A, 10V | |
Vgs(th) (Max) @ Id | 3V @ 4.38mA | |
Gate Charge (Qg) @ Vgs | 6.3nC @ 4.5V | |
Input Capacitance (Ciss) @ Vds | 5180pF @ 10V | |
Power - Max | 1.7W, 2.5W | |
Operating Temperature | -40°C ~ 85°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | 8-SMD, Flat Lead | |
Supplier Device Package | 8-HSO | |
Standard Package | 3,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | SC8673010L | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
SC8673010L is in stock for immediate shipping now. We are the distributor of Panasonic Electronic Components all series components. The condition of SC8673010L is new and unused, you can buy SC8673010L Panasonic Electronic Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SC8673010L.
