Manufacturer Part Number: | SBR-ST-29-P-ML |
---|---|
Manufacturer: | 3M |
Product Category: | Pluggable Connectors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | CONN SOCKET SAS 29POS VERT |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | SBR-ST-29-P-ML Datasheet |
Internal Part Number | 898-SBR-ST-29-P-ML | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Input/Output Connector Systems Primer | |
3D Model | SBR-ST-29-P-ML.igs SBR-ST-29-P-ML.x_t SBR-ST-29-P-ML.stp | |
PCN Design/Specification | SBR Series Intermateable 15/Dec/2009 | |
Category | Connectors, Interconnects | |
Family | Pluggable Connectors | |
Manufacturer | 3M | |
Series | SBR | |
Packaging | Tray | |
Part Status | Active | |
Connector Style | Receptacle | |
Connector Type | SAS | |
Number of Positions | 29 | |
Mounting Type | Through Hole | |
Termination | Press-Fit | |
Features | - | |
Contact Finish | Gold | |
Contact Finish Thickness | 30µin (0.76µm) | |
Standard Package | 1,500 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | SBR-ST-29-P-ML | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
SBR-ST-29-P-ML is in stock for immediate shipping now. We are the distributor of 3M all series components. The condition of SBR-ST-29-P-ML is new and unused, you can buy SBR-ST-29-P-ML 3M with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SBR-ST-29-P-ML.
