Manufacturer Part Number: | SA306-IHZ |
---|---|
Manufacturer: | Apex Microtechnology |
Product Category: | PMIC - Full, Half-Bridge Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC MOTOR DRIVER PWM 64QFP |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | SA306-IHZ Datasheet |
Internal Part Number | 898-SA306-IHZ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Standard Package | 1 | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Full, Half-Bridge Drivers | |
Manufacturer | Apex Microtechnology | |
Series | Apex Precision Power® | |
Packaging | Bulk | |
Part Status | Obsolete | |
Output Configuration | Half Bridge (3) | |
Applications | DC Motors, General Purpose, Solenoids | |
Interface | PWM | |
Load Type | Inductive | |
Technology | DMOS | |
Rds On (Typ) | 250 mOhm LS, 300 mOhm HS | |
Current - Output / Channel | 5A | |
Current - Peak Output | 17A | |
Voltage - Supply | 4.5 V ~ 5.5 V | |
Voltage - Load | 9 V ~ 60 V | |
Operating Temperature | -40°C ~ 150°C (TJ) | |
Features | - | |
Fault Protection | Current Limiting, Over Temperature, Shoot-Through, UVLO | |
Mounting Type | Surface Mount | |
Package / Case | 64-PowerQFP | |
Supplier Device Package | 64-PowerQFP | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | SA306-IHZ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
SA306-IHZ is in stock for immediate shipping now. We are the distributor of Apex Microtechnology all series components. The condition of SA306-IHZ is new and unused, you can buy SA306-IHZ Apex Microtechnology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SA306-IHZ.
