| Manufacturer Part Number: | SA160DPA |
|---|---|
| Manufacturer: | Apex Microtechnology |
| Product Category: | PMIC - Full, Half-Bridge Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC BRIDGE DRVR ANLG/PWM 12SIP DP |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | SA160DPA Datasheet |
| Internal Part Number | 898-SA160DPA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Analog Portfolio | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | Full, Half-Bridge Drivers | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Full, Half-Bridge Drivers | |
| Manufacturer | Apex Microtechnology | |
| Series | - | |
| Packaging | Bulk | |
| Part Status | Active | |
| Output Configuration | Half Bridge (2) | |
| Applications | DC Motors, General Purpose | |
| Interface | Analog, PWM | |
| Load Type | Inductive | |
| Technology | Power MOSFET | |
| Rds On (Typ) | 140 mOhm LS + HS | |
| Current - Output / Channel | 14A | |
| Current - Peak Output | 20A | |
| Voltage - Supply | 9.5 V ~ 15 V | |
| Voltage - Load | 80V (Max) | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Features | Internal Oscillators | |
| Fault Protection | - | |
| Mounting Type | Through Hole | |
| Package / Case | 12-PowerSIP | |
| Supplier Device Package | 12-POWER SIP | |
| Standard Package | 15 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | SA160DPA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
SA160DPA is in stock for immediate shipping now. We are the distributor of Apex Microtechnology all series components. The condition of SA160DPA is new and unused, you can buy SA160DPA Apex Microtechnology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SA160DPA.
