Manufacturer Part Number: | S8VM-30024C |
---|---|
Manufacturer: | Omron Automation and Safety |
Product Category: | AC DC Converters |
Available Quantity: | 9030 Pieces |
Unit Price: | Quote by Email |
Description: | AC/DC CONVERTER 24V 300W |
Lead Free Status / RoHS Status: | Lead free by exemption / RoHS compliant by exemption |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | S8VM-30024C Datasheet |
Internal Part Number | 898-S8VM-30024C | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Design/Specification | S8VM Family Jan/2013 Multiple Devices Nameplate May/2015 | |
Online Catalog | S8VM Series | |
Category | Power Supplies - External/Internal (Off-Board) | |
Family | AC DC Converters | |
Manufacturer | Omron Automation and Safety | |
Series | S8VM | |
Part Status | Active | |
Type | Enclosed | |
Number of Outputs | 1 | |
Voltage - Input | 85 ~ 264 VAC | |
Voltage - Output 1 | 24V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Voltage - Output 4 | - | |
Current - Output (Max) | 14A | |
Power (Watts) | 300W | |
Applications | ITE (Commercial) | |
Voltage - Isolation | 3kV (3000V) | |
Efficiency | 81% | |
Operating Temperature | -10°C ~ 70°C (With Derating) | |
Features | Adjustable Output, Universal Input | |
Mounting Type | Chassis Mount | |
Size / Dimension | 7.40" L x 3.29" W x 2.46" H (188.0mm x 83.5mm x 62.5mm) | |
Minimum Load Required | - | |
Approvals | CE, cULus, cURus, VDE | |
Power (Watts) - Max | 300W | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | S8VM-30024C | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
S8VM-30024C is in stock for immediate shipping now. We are the distributor of Omron Automation and Safety all series components. The condition of S8VM-30024C is new and unused, you can buy S8VM-30024C Omron Automation and Safety with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for S8VM-30024C.
