| Manufacturer Part Number: | S3022A |
|---|---|
| Manufacturer: | Crydom Co. |
| Product Category: | Solid State Relays |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Solid State Relay SPST-NO (1 Form A) Module |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | S3022A Datasheet |
| Internal Part Number | 898-S3022A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| Category | Relays | |
| Family | Solid State Relays | |
| Manufacturer | Crydom Co. | |
| Series | 3 | |
| Packaging | Bulk | |
| Part Status | Obsolete | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC, Zero Cross | |
| On-State Resistance (Max) | - | |
| Load Current | 3A | |
| Voltage - Input | 3.5 ~ 8VDC | |
| Voltage - Load | 40 ~ 280 V | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Package / Case | Module | |
| Supplier Device Package | - | |
| Relay Type | Relay | |
| Standard Package | 10 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | S3022A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
S3022A is in stock for immediate shipping now. We are the distributor of Crydom Co. all series components. The condition of S3022A is new and unused, you can buy S3022A Crydom Co. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for S3022A.
