Manufacturer Part Number: | RP8200B2M1CEBLKBLKWHT |
---|---|
Manufacturer: | E-Switch |
Product Category: | Pushbutton Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Pushbutton Switch SPST Standard, Illuminated Panel Mount, Front |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | RP8200B2M1CEBLKBLKWHT Datasheet |
Internal Part Number | 898-RP8200B2M1CEBLKBLKWHT | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | RP8200B2M1CEBLKyyyyyy.stp | |
Category | Switches | |
Family | Pushbutton Switches | |
Manufacturer | E-Switch | |
Series | RP8200 | |
Packaging | Bulk | |
Part Status | Active | |
Type | Standard, Illuminated | |
Circuit | SPST | |
Switch Function | Off-On | |
Current Rating | 100mA (DC) | |
Voltage Rating - AC | - | |
Voltage Rating - DC | 24V | |
Actuator Type | Round, Button | |
Color - Actuator/Cap | Black | |
Illumination Type, Color | LED, White | |
Illumination Voltage (Nominal) | 3.5 VDC | |
Mounting Type | Panel Mount, Front | |
Termination Style | Solder Lug | |
Ingress Protection | IP67 - Dust Tight, Waterproof | |
Features | - | |
Panel Cutout Dimensions | Circular - 13.60mm Dia | |
Operating Temperature | -30°C ~ 85°C | |
Mechanical Life | - | |
Electrical Life | 200,000 Cycles | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | RP8200B2M1CEBLKBLKWHT | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
RP8200B2M1CEBLKBLKWHT is in stock for immediate shipping now. We are the distributor of E-Switch all series components. The condition of RP8200B2M1CEBLKBLKWHT is new and unused, you can buy RP8200B2M1CEBLKBLKWHT E-Switch with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for RP8200B2M1CEBLKBLKWHT.
