Manufacturer Part Number: | RN131C/RM475 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | RF Transceiver Modules |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | RF TXRX MOD WIFI CHIP + U.FL ANT |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | RN131C/RM475 Datasheet |
Internal Part Number | 898-RN131C/RM475 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Other Related Documents | RN WiFLY Presentation | |
Design Resources | Development Tool Selector IoT Product Selector | |
PCN Assembly/Origin | RN131 Label/Packing/Assembly Chg 12/Jul/2016 | |
Online Catalog | RN131 | |
Category | RF/IF and RFID | |
Family | RF Transceiver Modules | |
Manufacturer | Microchip Technology | |
Series | - | |
Packaging | Tray | |
Part Status | Active | |
RF Family/Standard | WiFi | |
Protocol | 802.11b/g | |
Modulation | CDK, DBPSK, DQPSK, DSSS, OFDM | |
Frequency | 2.4GHz | |
Data Rate | 54Mbps | |
Power - Output | 18dBm | |
Sensitivity | -85dBm | |
Serial Interfaces | SPI, UART | |
Antenna Type | Integrated, Chip + U.FL | |
Memory Size | 8MB Flash, 2MB ROM, 128kB RAM | |
Voltage - Supply | 3 V ~ 3.7 V | |
Current - Receiving | 40mA | |
Current - Transmitting | 140mA | |
Mounting Type | Surface Mount | |
Operating Temperature | 0°C ~ 70°C | |
Package / Case | Module | |
Standard Package | 20 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | RN131C/RM475 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
RN131C/RM475 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of RN131C/RM475 is new and unused, you can buy RN131C/RM475 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for RN131C/RM475.
