| Manufacturer Part Number: | RJH60D3DPE-00#J3 |
|---|---|
| Manufacturer: | Renesas Electronics America |
| Product Category: | Transistors - IGBTs - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IGBT Trench 600V 35A 113W Surface Mount 4-LDPAK |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | RJH60D3DPE-00#J3 Datasheet |
| Internal Part Number | 898-RJH60D3DPE-00#J3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | Standard IGBTs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - IGBTs - Single | |
| Manufacturer | Renesas Electronics America | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| IGBT Type | Trench | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 35A | |
| Current - Collector Pulsed (Icm) | - | |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 17A | |
| Power - Max | 113W | |
| Switching Energy | 200µJ (on), 210µJ (off) | |
| Input Type | Standard | |
| Gate Charge | 37nC | |
| Td (on/off) @ 25°C | 35ns/80ns | |
| Test Condition | 300V, 17A, 5 Ohm, 15V | |
| Reverse Recovery Time (trr) | 100ns | |
| Package / Case | SC-83 | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 4-LDPAK | |
| Standard Package | 1,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | RJH60D3DPE-00#J3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
RJH60D3DPE-00#J3 is in stock for immediate shipping now. We are the distributor of Renesas Electronics America all series components. The condition of RJH60D3DPE-00#J3 is new and unused, you can buy RJH60D3DPE-00#J3 Renesas Electronics America with us at a very low price and quick delivery.
