| Manufacturer Part Number: | RI-80SMD0515-J |
|---|---|
| Manufacturer: | Coto Technology |
| Product Category: | Magnetic, Reed Switches |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Glass Body Reed Switch SPST-NO 5 ~ 15AT Operate Range 5W 250mA (AC), 350mA (DC) 140V Surface Mount |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | RI-80SMD0515-J Datasheet |
| Internal Part Number | 898-RI-80SMD0515-J | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Switches | |
| Family | Magnetic, Reed Switches | |
| Manufacturer | Coto Technology | |
| Series | RI-80 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Type | Glass Body | |
| Circuit | SPST-NO | |
| Operate Range | 5 ~ 15AT | |
| Release Range | 2 ~ 13AT | |
| Current - Switching | 250mA (AC), 350mA (DC) | |
| Voltage - Switching AC | 140V | |
| Voltage - Switching DC | 175V | |
| Power - Rated | 5W | |
| Operate Time | 0.35ms | |
| Release Time | 0.02ms | |
| Mounting Type | Surface Mount | |
| Termination Style | J Lead | |
| Length - Overall | 0.279" (7.09mm) | |
| Size - Body | 0.071" Dia x 0.197" L (1.80mm x 5.00mm) | |
| Height Above Board | 0.076" (1.92mm) | |
| Operating Temperature | -55°C ~ 125°C | |
| Capacitance | 0.45pF | |
| Current - Carry | 500mA (AC/DC) | |
| Standard Package | 7,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | RI-80SMD0515-J | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
RI-80SMD0515-J is in stock for immediate shipping now. We are the distributor of Coto Technology all series components. The condition of RI-80SMD0515-J is new and unused, you can buy RI-80SMD0515-J Coto Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for RI-80SMD0515-J.
