QS101XXR12

QS101XXR12
Manufacturer Part Number:QS101XXR12
Manufacturer:
Product Category:Panel Indicators, Pilot Lights
Available Quantity:9046 Pieces
Unit Price:Quote by Email
Description:LED Panel Indicator Red Diffused 30° 12V 20mA Round with Flat Top, 12.00mm Solder Lug
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: QS101XXR12 Datasheet
QS101XXR12´s Parameters
Internal Part Number898-QS101XXR12
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog QS Series
CategoryOptoelectronics
FamilyPanel Indicators, Pilot Lights
ManufacturerApem Inc.
SeriesQS
Part StatusActive
TypeLED
Lamp ColorRed
Lens ColorRed
Lens TransparencyDiffused
RatingsDC
Voltage12V
Current20mA
Panel Cutout ShapeRound
Panel Cutout Dimensions0.39" (9.91mm)
Lens Style/SizeRound with Flat Top, 12.00mm
Millicandela Rating25mcd
Wavelength - Peak-
Viewing Angle30°
Termination StyleSolder Lug
Ingress Protection-
Features-
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartQS101XXR12
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

QS101XXR12 is in stock for immediate shipping now. We are the distributor of Apem Inc. all series components. The condition of QS101XXR12 is new and unused, you can buy QS101XXR12 Apem Inc. with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for QS101XXR12.
