Manufacturer Part Number: | Q48SK12018NRFA |
---|---|
Manufacturer: | Delta Electronics |
Product Category: | DC DC Converters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | MODULE POWER DC/DC 4TH BRICK 12V |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | Q48SK12018NRFA Datasheet |
Internal Part Number | 898-Q48SK12018NRFA | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Featured Product | DC/DC Converters – Delta Product Groups | |
PCN Obsolescence/ EOL | E48SD12020NRFA,Q48SK120xxNRFx 26/Jun/2013 | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | Delta Electronics | |
Series | Delphi Q48SK | |
Packaging | Tray | |
Part Status | Obsolete | |
Type | Isolated Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 36V | |
Voltage - Input (Max) | 75V | |
Voltage - Output 1 | 12V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 18A | |
Power (Watts) - Manufacture Series | 216W | |
Voltage - Isolation | 2.25kV (2250V) | |
Applications | ITE (Commercial) | |
Features | Remote On/Off, OCP, OTP, OVP, UVLO | |
Mounting Type | Through Hole | |
Package / Case | 6-DIP Module, 1/4 Brick | |
Size / Dimension | 2.28" L x 1.45" W x 0.43" H (57.9mm x 36.8mm x 10.9mm) | |
Operating Temperature | -40°C ~ 117°C | |
Efficiency | 95.5% | |
Power (Watts) - Max | 216W | |
Standard Package | 90 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | Q48SK12018NRFA | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
Q48SK12018NRFA is in stock for immediate shipping now. We are the distributor of Delta Electronics all series components. The condition of Q48SK12018NRFA is new and unused, you can buy Q48SK12018NRFA Delta Electronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for Q48SK12018NRFA.
