| Manufacturer Part Number: | PX3516ADDGR4XTMA1 |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | PMIC - Gate Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC BUCK SYNC DRIVER DL TDSON10-2 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PX3516ADDGR4XTMA1 Datasheet |
| Internal Part Number | 898-PX3516ADDGR4XTMA1 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | PX3516ADDG-R4 EOL 12/JAN/2016 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Manufacturer | Infineon Technologies | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Last Time Buy | |
| Driven Configuration | Half-Bridge | |
| Channel Type | Synchronous | |
| Number of Drivers | 2 | |
| Gate Type | N-Channel MOSFET | |
| Voltage - Supply | 4.5 V ~ 6 V | |
| Logic Voltage - VIL, VIH | 1.3V, 1.9V | |
| Current - Peak Output (Source, Sink) | 2A, 2A | |
| Input Type | Non-Inverting | |
| High Side Voltage - Max (Bootstrap) | 30V | |
| Rise / Fall Time (Typ) | 10ns, 10ns | |
| Operating Temperature | -25°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-VFDFN Exposed Pad | |
| Supplier Device Package | TDSON-10-2 | |
| Standard Package | 4,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PX3516ADDGR4XTMA1 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PX3516ADDGR4XTMA1 is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of PX3516ADDGR4XTMA1 is new and unused, you can buy PX3516ADDGR4XTMA1 Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PX3516ADDGR4XTMA1.
