Stocking distributor of Electronic Components
Email: [email protected]
| Manufacturer Part Number: | PVI1050NS-TPBF |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | Optoisolators - Transistor, Photovoltaic Output |
| Available Quantity: | 12010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Optoisolator Photovoltaic Output 2500Vrms 2 Channel 8-SMD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 4 (72 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PVI1050NS-TPBF Datasheet |
| Internal Part Number | 898-PVI1050NS-TPBF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) | |
| PCN Assembly/Origin | MER Devices Fab Site 09/Dec/2013 | |
| PCN Other | MSL Level 4 Update 04/May/2015 | |
| Online Catalog | PVI-NPbF Series | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Manufacturer | Infineon Technologies | |
| Series | PVI | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Number of Channels | 2 | |
| Voltage - Isolation | 2500Vrms | |
| Current Transfer Ratio (Min) | - | |
| Current Transfer Ratio (Max) | - | |
| Turn On / Turn Off Time (Typ) | 300µs, 220µs (Max) | |
| Rise / Fall Time (Typ) | - | |
| Input Type | DC | |
| Output Type | Photovoltaic | |
| Voltage - Output (Max) | 5V | |
| Current - Output / Channel | 5µA | |
| Voltage - Forward (Vf) (Typ) | - | |
| Current - DC Forward (If) (Max) | - | |
| Vce Saturation (Max) | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD (4 Leads), Gull Wing | |
| Supplier Device Package | 8-SMD | |
| Standard Package | 750 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PVI1050NS-TPBF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PVI1050NS-TPBF is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of PVI1050NS-TPBF is new and unused, you can buy PVI1050NS-TPBF Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PVI1050NS-TPBF.
