| Manufacturer Part Number: | PTKM10-180SM |
|---|---|
| Manufacturer: | API Delevan Inc. |
| Product Category: | Fixed Inductors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 10µH Shielded Toroidal Inductor 1.6A 100 mOhm Max Nonstandard |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PTKM10-180SM Datasheet |
| Internal Part Number | 898-PTKM10-180SM | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | PTKM-SM Series | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Manufacturer | API Delevan Inc. | |
| Series | PTKM-SM | |
| Packaging | Bulk | |
| Part Status | Active | |
| Type | Toroidal | |
| Material - Core | Ferrite | |
| Inductance | 10µH | |
| Tolerance | ±10% | |
| Current Rating | 1.6A | |
| Current - Saturation | 430mA | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 100 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | 35MHz | |
| Ratings | - | |
| Operating Temperature | - | |
| Frequency - Test | 1kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.340" L x 0.340" W (8.64mm x 8.64mm) | |
| Height - Seated (Max) | 0.300" (7.62mm) | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PTKM10-180SM | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PTKM10-180SM is in stock for immediate shipping now. We are the distributor of API Delevan Inc. all series components. The condition of PTKM10-180SM is new and unused, you can buy PTKM10-180SM API Delevan Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PTKM10-180SM.
